Protective adapter cable / extension cable for outdoors with RCD (outdoor extension cable for use on construction sites and permanent outdoor use, IP44, 2m cable)
Description
The protective adapter cable consists of a 2m long cable with an RCD plug and a protective contact coupling. Thanks to its very robust design, the extension cable is ideally suited for use on construction sites and permanent outdoor use. The RCD plug has a function check indicator and also impresses with the following features:
- With IP 44 RCD plug and splash-proof coupling
- For maximum safety when using electrical appliances
- Tripping time: <30 ms
- Tripping current: 30 mA
- Operating temperature: -25 °C to 40 °C
Protection against contact with tools, wires or similar with ? >1.0 mm, protection against foreign bodies with ? > 1.0 mm. As well as protection against splash water from all directions
An RCD (residual current circuit breaker) is an electrical protective device that is primarily used to protect against electric shocks. The RCD recognises the difference between the incoming and outgoing current in a circuit and automatically switches off the circuit in the event of a residual current. When used for personal protection, a residual current device must trip and interrupt the circuit at a residual current of 30mA at the latest.
Technical data
- Cable designation: H07RN-F 3G1,5
- Cable length: 2 m
- Cable quality: Rubber-Neoprene
- With residual current circuit breaker (RCCB): Yes
- Nominal input voltage: 250 V
- Connection: Earthed coupling
- Degree of protection (IP): IP44
- Suitable for outdoor area: Yes
- Width of product (without packaging): 20 cm
- Weight of product (without packaging): 0,63 kg
- Height of product (without packaging): 7,40 cm
- Length of product (without packaging): 24 cm
